Marketed: April 1992
Original Price: 357,000 yen
Although quite compact and light weight, the RC-560 was a full-feature (record / playback / erasure) still video camera.
The RC-560 used a 1/2 inch 410,000 pixel CCD image sensor and Hi-band specification to produce excellent images with horizontal resolution of 450 TV lines and improved vertical resolution using frame recording.
The 3X zoom lens and integral ultra-compact automatic flash were among its improved specifications.
RC-ION 560
Type Lens Shutter Still Video Camera
Image Sensor CCD Image Sensor (410,000 pix)
Image Sensor Size 1/2"
Recording Format Still Video Format (High-band)
Recording media Still Video Floppy Disk
Lens 8-24mm F2.5-2.7
Shutter Lens Shutter
Shutter Speed 1/500 - 1/30 [sec]
Resolution [Horizontal] more than 450 TV lines
Sensitivity ISO 70 (Frame) / ISO 140 (Field)
Video Signal NTSC
Power Supply Battery Pack Bp-4P; Battery Pack Bp-A8; AC Couper
AR-570
Dimensions (W x H x D) 148(W)X46.5(H)X125(D)mm
Weight 550g (without Battery , Floppy Disk)
RC-ION 560
RC-ION 560
Still video camera
