Marketed: March 2004
Original Price: Open Price (set by dealer)
The Canon PowerShot Pro1 is the new flagship model in Canon’s PowerShot series of compact digital cameras. Offering the most advanced specifications in the series, the Pro1 features an eight-megapixel CCD image sensor for class-leading resolution, and a built-in Canon L (Luxury) Lens which, renowned in the company’s EF-series lineup of interchangeable lenses for EOS AF SLR cameras, delivers superlative image quality.Maximizing the benefit of the image sensor’s eight-megapixel resolution, the PowerShot Pro1’s L Lens marks a world first for a compact digital camera with the inclusion of a fluorite lens element, in addition to UD (ultra-low dispersion) and aspherical lens elements. As a result the L Lens effectively corrects for a variety of aberrations, including secondary spectrum (residual chromatic aberration), for exceptional image quality throughout the zoom range. Though compact in size, the lens realizes a 7x (equivalent to 28-200mm in 35mm format) optical zoom ratio enabling a broad shooting range from wide angle to telephoto. Also, while realizing a high zoom ratio, the lens is exceptionally bright, offering a maximum-aperture range of f/2.4-3.5 to permit the use of fast shutter speeds in low-light conditions as well as making possible background blur effects.
PowerShot Pro 1
TYPE OF CAMERA
Type of Camera Compact digital still camera with built-in
flash, 7.0x Optical/3.2x Digital/ 22x Combined
Zoom
IMAGE CAPTURE DEVICE
Type 2/3" Charge-Coupled Device (CCD)
Total Pixels Approx. 8.3 million
LENS
Focal Length 7.2 – 50.8mm, f/2.4 – 3.5 zoom lens
(35mm film equivalent: 28 – 200mm)
Digital Zoom 3.2x
Focusing Range Normal:50cm (1.6 ft.) – Infinity
(W – 63mm equivalent) 1m (3.3 ft.) – Infinity
(63mm equivalent – T)
Normal + Tele-converter: 2.2m
(7.2 ft.) – Infinity (126mm equivalent – T)
Normal + Close-up Lens: 33 – 50cm
(1.1 – 1.6 ft.) (T)
Macro:10 – 50cm (3.9 in. – 1.6 ft.)
(W – 63mm equivalent)30 – 50cm
(1.0 – 1.6 ft.) (63 – 90mm equivalent)
Super Macro:3 – 30cm (1.2 in. – 1.0 ft.)
(42 – 90mm equivalent)
Manual:10cm (3.9 in.) – Infinity
(W – 63mm equivalent) 30cm
(1.0 ft.) – Infinity
(63mm – 90mm equivalent) 1m
(3.3 ft.) – Infinity (90mm equivalent – T)
Autofocus 1-point AF (Center Point or FlexiZone AF is
available according to shooting mode)
VIEWFINDERS
Optical Viewfinder Not available
LCD Monitor 2.0" low temperature polycrystalline silicon
TFT color LCD with variable-angle function.
LCD Pixels Approx. 235,000 pixels
LCD Coverage 100%
APERTURE AND SHUTTER
Maximum Aperture f/2.4 – 8.0 (W), f/3.5 – 8.0 (T)
Shutter Speed 15 – 1/4,000 sec.
EXPOSURE CONTROL
Sensitivity AUTO; ISO 50/100/200/400 equivalent
Light Metering Method Evaluative/Center-weighted average/Spot
Exposure Control Method Program AE, Shutter-Priority AE, Aperture-
Priority AE, Manual
AE Lock Available
ND Filter Available (On: Approx. three stops reduction)
WHITE BALANCE
White Balance Control Auto, Pre-set (Daylight, Cloudy, Tungsten,
Fluorescent, Fluorescent H, Flash),
or Custom White Balance(2 positions)
FLASH (BUILT-IN)
Operation Modes Auto, Red-Eye Reduction On/Off
Flash Range WIDE: 50cm – 5.0m (1.6 – 16.4 ft.)
TELE: 1m – 3.5m (3.3 – 11 ft.)
(When sensitivity is set to ISO 100
equivalent)
Recycling Time Approx. 10 sec. or shorter (battery
voltage = 7.4V)
Terminals for External Flash Sync-terminals at accessory shoe.Automatic
E-TTL Flash is possible with EX-series
Speedlites: Canon Speedlite 550EX, 420EX,
380EX, 200EX, Macro Ring Lite MR-14EX and
Macro Twin Lite MT-24EX.
Flash Exposure Compensation +/- 2.0EV (at every 1/3-stop)
SHOOTING SPECIFICATIONS
Shooting Modes Auto, Creative (P, Av, Tv, M, Custom 1,
Custom 2), Image zone (Portrait, Landscape,
Night Scene, Stitch Assist, Movie)
Self-Timer Operates with approx. 2 sec. or approx
10 sec. count-down
Wireless Control Available (playback is available too)
Continuous Shooting High Speed: Approx. 2.5 images/sec.,
Normal: Approx. 1.0 images/sec.
(at Large/ Fine mode and LCD monitor is OFF)
Photo Effects Effect off, Vivid, Neutral, Low Sharpening,
Sepia, Black & White and Custom effect
IMAGE STORAGE
Storage Media CompactFlash (CF) Card Type I or Type II
Print Order Design rule for camera file system,
Digital Print
Format Order Format (DPOF) Version 1.1
Image Recording Format Exif (JPEG 2.21)/ RAW
JPEG Compression Mode SuperFine, Fine or Normal
Number of Recording Pixels Still Image: 3,264 x 2,448 (Large),
2,272 x 1,704 (Medium 1),
1,600 x 1,200 (Medium 2),
1,024 x 768 (Medium3),
640 x 480 (Small)
Movie: 640 x 480, 320 x 240, 160 x 120
NUMBER OF RECORDABLE IMAGES
Menu Selection File Size Resolution 32MB 64MB 256MB 512MB 1GB
(KB) (pixels)
Large/SuperFine 3,436 3,264*2,448 8 17 72 144 300
Large/Fine 2,060 3,264*2,448 14 29 120 240 496
Large/Normal 980 3,264*2,448 30 62 252 503 1,024
Medium 1/ 2,002 2,272*1,704 14 30 123 247 512
SuperFine
Medium 1/Fine 1,116 2,272*1,704 27 54 222 442 910
Medium 1/Normal 556 2,272*1,704 54 110 443 879 1,726
Medium 2/ 1,002 1,600*1,200 30 61 246 491 993
SuperFine
Medium 2/Fine 558 1,600*1,200 54 109 440 879 1,726
Medium 2/Normal 278 1,600*1,200 108 217 868 1,734 3,283
Medium 3/ 570 1,024* 768 53 107 431 855 1,726
SuperFine
Medium 3/Fine 320 1,024* 768 94 189 762 1,522 2,982
Medium 3/Normal 170 1,024* 768 174 349 1,390 2,741 4,687
Small/SuperFine 249 640* 480 120 241 962 1,891 3,845
Small/Fine 150 640* 480 196 393 1,563 3,112 5,468
Small/Normal 84 640* 480 337 676 2,720 5,203 8,202
RAW 9,020 2,592*1,944 2 6 26 54 115
* These figures reflect standard shooting conditions established by Canon. Actual totals and file sizes may vary according to the subject, shooting conditions and shooting mode.
TIME OF RECORDABLE MOVIES
Menu Selection Resolution 32MB 64MB 256MB 512MB 1GB
(pixels)
Movie/High 640*480 30 sec. 61 sec. 249 sec. 449 sec. 1,024 sec.
Movie/Medium 320*240 91 sec. 183 sec. 735 sec. 1,451 sec. 2,733 sec.
Movie/Low 160*120 242 sec. 489 sec. 1,954 sec. 3,902 sec. 6,562 sec.
*Above-written figures are measured under Canon's standard conditions and may vary depending on the scene, subjects or camera settings. Total length of movie files recordable on specific CF cards; Individual movie clips are limited to 3 minutes maximum per clip.
PLAYBACK SPECIFICATIONS
Playback Modes File Single, Index (9 thumbnail images),
Magnification (approx. 2.0x to 10x), Movie
ERASING SPECIFICATIONS
Erase Modes Erase Modes Still Images: Single Image, All
ImagesMovie: Part of Movie, All Movie
INTERFACES
Computer Interface Universal Serial Bus (USB) (mini-B jack)
Video Out NTSC or PAL
Audio Out Monaural
Other CF card slot (accepts Type I and Type II
cards). Direct connection to Canon Card Photo
Printers and select BJ Printers (no computer
required)
POWER SUPPLY
Power Source 1. Rechargeable Lithium-ion battery
(type: BP-511or BP-512)
2. AC adapter (type: CA-560)
3. Car battery adapter (type: CR-560)
4. Coin-type secondary Lithium battery
(CR-2016)
NUMBER of SHOTS
Electric View Finder LCD
BP-511 / BP-512 Approx. 420
Shooting Capacity(BP-511) Approx. 420*1
Playback Time (BP-511) Approx. 400 minutes (under Canon's standard
conditions*2 with full-charged battery)
PHYSICAL SPECIFICATIONS
Operating Temperature 32 – 104°F (0 – 40°C)
Operating Humidity 10 – 90%
Dimensions (W x H x D) 17.5 x 72 x 90.3mm(4.63 x 2.84 x 3.56 in.)
(Excluding viewfinder and protrusions)
Weight Approx. 545g(19.2 oz.) (camera body only)
